Magna-Power strives to offer its built-to-order products with the shortest manufacturing time possible by investing in inventory and integrating manufacturing processes internally. Nearly all products can be built-to-order within 2-4 weeks. Magna-Power has a limited amount of inventory of ready-built products. The listing below provides a real-time inventory of Magna-Power’s products currently in stock.

SL Serie

Model Voltage Maximum (Vdc) Current Maximum (Adc) Power Rating AC Input Voltage
SL10-150/208 0-10 Vdc 0-150 Adc 0-1.5 kW 187-229 Vac, 6 Aac, 50-400 Hz, 3Φ
SL10-150/UI 0-10 Vdc 0-150 Adc 0-1.5 kW 85-265 Vac, 21-7 Aac, 50-400 Hz, 1Φ
SL160-9/240 0-160 Vdc 0-9 Adc 0-1.5 kW 216-264 Vac, 6 Aac, 50-400 Hz, 3Φ
SL200-7.5/UI+LXI 0-200 Vdc 0-7.5 Adc 0-1.5 kW 85-265 Vac, 21-7 Aac, 50-400 Hz, 1Φ
SL200-7.5/UI+LXI 0-200 Vdc 0-7.5 Adc 0-1.5 kW 85-265 Vac, 21-7 Aac, 50-400 Hz, 1Φ
SL200-7.5/UI+LXI 0-200 Vdc 0-7.5 Adc 0-1.5 kW 85-265 Vac, 21-7 Aac, 50-400 Hz, 1Φ
SL200-7.5/UI+LXI 0-200 Vdc 0-7.5 Adc 0-1.5 kW 85-265 Vac, 21-7 Aac, 50-400 Hz, 1Φ
SL200-7.5/UI+LXI 0-200 Vdc 0-7.5 Adc 0-1.5 kW 85-265 Vac, 21-7 Aac, 50-400 Hz, 1Φ
SL20-75/208+GPIB 0-20 Vdc 0-75 Adc 0-1.5 kW 187-229 Vac, 6 Aac, 50-400 Hz, 3Φ
SL32-46/208+LXI 0-32 Vdc 0-46 Adc 0-1.5 kW 187-229 Vac, 6 Aac, 50-400 Hz, 3Φ
SL32-46/UI+LXI 0-32 Vdc 0-46 Adc 0-1.5 kW 85-265 Vac, 21-7 Aac, 50-400 Hz, 1Φ
SL32-46/UI+LXI 0-32 Vdc 0-46 Adc 0-1.5 kW 85-265 Vac, 21-7 Aac, 50-400 Hz, 1Φ
SL32-46/UI+LXI 0-32 Vdc 0-46 Adc 0-1.5 kW 85-265 Vac, 21-7 Aac, 50-400 Hz, 1Φ
SL50-30/208+LXI 0-50 Vdc 0-30 Adc 0-1.5 kW 187-229 Vac, 6 Aac, 50-400 Hz, 3Φ
SL5-250/UI 0-5 Vdc 0-250 Adc 0-1.5 kW 85-265 Vac, 21-7 Aac, 50-400 Hz, 1Φ
SL600-2.5/UI+LXI 0-600 Vdc 0-2.5 Adc 0-1.5 kW 85-265 Vac, 21-7 Aac, 50-400 Hz, 1Φ
SL600-2.5/UI+LXI 0-600 Vdc 0-2.5 Adc 0-1.5 kW 85-265 Vac, 21-7 Aac, 50-400 Hz, 1Φ
SL60-25/UI+HS+LXI 0-60 Vdc 0-25 Adc 0-1.5 kW 85-265 Vac, 21-7 Aac, 50-400 Hz, 1Φ
SL60-25/UI+HS+LXI 0-60 Vdc 0-25 Adc 0-1.5 kW 85-265 Vac, 21-7 Aac, 50-400 Hz, 1Φ
SL60-25/UI+HS+LXI 0-60 Vdc 0-25 Adc 0-1.5 kW 85-265 Vac, 21-7 Aac, 50-400 Hz, 1Φ
SL60-25/UI+HS+LXI 0-60 Vdc 0-25 Adc 0-1.5 kW 85-265 Vac, 21-7 Aac, 50-400 Hz, 1Φ
SL60-25/UI+HS+LXI 0-60 Vdc 0-25 Adc 0-1.5 kW 85-265 Vac, 21-7 Aac, 50-400 Hz, 1Φ
SL60-25/UI+HS+LXI 0-60 Vdc 0-25 Adc 0-1.5 kW 85-265 Vac, 21-7 Aac, 50-400 Hz, 1Φ
SL60-25/UI+HS+LXI 0-60 Vdc 0-25 Adc 0-1.5 kW 85-265 Vac, 21-7 Aac, 50-400 Hz, 1Φ
SL80-18/UI+LXI 0-80 Vdc 0-18 Adc 0-1.5 kW 85-265 Vac, 21-7 Aac, 50-400 Hz, 1Φ
SL80-18/UI+LXI 0-80 Vdc 0-18 Adc 0-1.5 kW 85-265 Vac, 21-7 Aac, 50-400 Hz, 1Φ
SL80-18/UI+LXI 0-80 Vdc 0-18 Adc 0-1.5 kW 85-265 Vac, 21-7 Aac, 50-400 Hz, 1Φ
SL80-18/UI+LXI 0-80 Vdc 0-18 Adc 0-1.5 kW 85-265 Vac, 21-7 Aac, 50-400 Hz, 1Φ
SL1000-2.6/480+LXI 0-1000 Vdc 0-2.6 Adc 0-2.6 kW 432-528 Vac, 6 Aac, 50-400 Hz, 3Φ
SL1000-4.0/208 0-1000 Vdc 0-4.0 Adc 0-4 kW 187-229 Vac, 16 Aac, 50-400 Hz, 3Φ
SL32-125/208+LXI 0-32 Vdc 0-125 Adc 0-4 kW 187-229 Vac, 16 Aac, 50-400 Hz, 3Φ
SL50-80/208+LXI 0-50 Vdc 0-80 Adc 0-4 kW 187-229 Vac, 16 Aac, 50-400 Hz, 3Φ
SL32-186/240 0-32 Vdc 0-186 Adc 0-6 kW 216-264 Vac, 24 Aac, 50-400 Hz, 3Φ
SL1000-8.0/208 0-1000 Vdc 0-8.0 Adc 0-8 kW 187-229 Vac, 32 Aac, 50-400 Hz, 3Φ
SL1000-8.0/480 0-1000 Vdc 0-8.0 Adc 0-8 kW 432-528 Vac, 17 Aac, 50-400 Hz, 3Φ
SL32-250/208 0-32 Vdc 0-250 Adc 0-8 kW 187-229 Vac, 32 Aac, 50-400 Hz, 3Φ
SL32-250/480 0-32 Vdc 0-250 Adc 0-8 kW 432-528 Vac, 17 Aac, 50-400 Hz, 3Φ

XR Serie

Model Voltage Maximum (Vdc) Current Maximum (Adc) Power Rating AC Input Voltage
XR2000-5.0/240 0-2000 Vdc 0-5.0 Adc 0-10 kW 216-264 Vac, 36 Aac, 50-400 Hz, 3Φ
XR1000-2.0/240SP 0-1000 Vdc 0-2.0 Adc 0-2 kW 216-264 Vac, 18 Aac, 50-400 Hz, 1Φ
XR2000-1.0/208 0-2000 Vdc 0-1.0 Adc 0-2 kW 187-229 Vac, 8 Aac, 50-400 Hz, 3Φ
XR32-62/240 0-32 Vdc 0-62 Adc 0-2 kW 216-264 Vac, 8 Aac, 50-400 Hz, 3Φ
XR6000-0.33/240POS 0-6000 Vdc 0-0.33 Adc 0-2 kW 216-264 Vac, 8 Aac, 50-400 Hz, 3Φ
XR32-124/208 0-32 Vdc 0-124 Adc 0-4 kW 187-229 Vac, 15 Aac, 50-400 Hz, 3Φ
XR5-600/380 0-5 Vdc 0-600 Adc 0-4 kW 342-418 Vac, 9 Aac, 50-400 Hz, 3Φ
XR5-600/480+LXI 0-5 Vdc 0-600 Adc 0-4 kW 432-528 Vac, 8 Aac, 50-400 Hz, 3Φ

TS Serie

Model Voltage Maximum (Vdc) Current Maximum (Adc) Power Rating AC Input Voltage

MT Serie

Model Voltage Maximum (Vdc) Current Maximum (Adc) Power Rating AC Input Voltage
MTD600-160/480+HS 0-600 Vdc 0-160 Adc 0-100 kW 432-528 Vac, 160 Aac, 50-60 Hz, 3Φ
MTD1500-100/380+HS 0-1500 Vdc 0-100 Adc 0-150 kW 342-418 Vac, 278 Aac, 50-60 Hz, 3Φ
